ROTEL A10 mkII integrated stereo amplifier

Rotel A10MKII Integrated Amplifier

The Rotel A10MKII Integrated Amplifier offers a combination of power, simplicity and style for music lovers seeking a straightforward analog Hi-Fi system. Its Class A/B amplifier design delivers 50 Watts per channel into 8 ohms and 60 Watts per channel into 4 ohms.

Constructed around a linear power supply featuring a massive Rotel-built toroidal power transformer, the A10MKII provides a high-current foundation for its Class A/B output stage. Three line-level RCA inputs and a Moving Magnet compatible Phono stage accommodate a range of analog sources.

Key Features

• 50 Watts per channel into 8 ohms and 60 Watts per channel into 4 ohms.
• Class A/B amplifier design.
• High-current linear power supply.
• Massive Rotel-built toroidal power transformer.
• Three line-level RCA inputs for analog sources.
• Moving Magnet Phono input for turntable connection.
• Dedicated headphone amplifier circuit with front-panel 1/8-inch headphone jack.
• Rotary Bass, Treble and Balance controls.
• Motorized analog volume controller.
• IR remote control included.
• Available in black and silver.

Class A/B Amplification

The A10MKII delivers an authoritative 50 Watts per channel of Class A/B power into 8 ohms, with output increasing to 60 Watts per channel into 4-ohm loads. Its amplifier architecture is designed to provide the power required for a wide range of stereo loudspeakers.

Rotel-Built Toroidal Transformer

At the heart of the A10MKII is a linear power supply featuring a massive Rotel-built toroidal power transformer. The high-current power supply provides a solid electrical foundation for the Class A/B amplifier circuitry.

Rotel's in-house transformer manufacturing allows this critical component to be engineered specifically for the requirements of the amplifier.

All-Analog Connectivity

All analog sources are welcome, with three line-level RCA inputs available for compatible source components. CD players, network streamers, external DACs and other components with analog outputs can be connected directly to the amplifier.

The A10MKII maintains a straightforward analog approach without adding unnecessary digital or network functions.

Moving Magnet Phono Stage

For vinyl enthusiasts, the A10MKII includes a built-in Moving Magnet compatible Phono stage, allowing a compatible turntable to be connected directly without requiring an external phono preamplifier.

The MM Phono input has a sensitivity of 1.5mV and an input impedance of 43kΩ, with a specified frequency response of 20Hz to 20kHz and an 85dB signal-to-noise ratio.

Dedicated Headphone Amplifier

A front-panel 1/8-inch headphone jack with a dedicated headphone amplifier circuit provides convenient private listening without the need for a separate headphone amplifier.

Intuitive Controls

The intuitive front-panel layout includes rotary Bass, Treble and Balance controls. Tone controls provide ±6dB adjustment at 100Hz and 10kHz.

A motorized analog volume controller maintains traditional tactile operation while also allowing volume adjustment from the listening position using the included IR remote control.

Classic Rotel Design

The A10MKII is available in both black and silver finishes. Its low-profile chassis and straightforward front-panel layout make it easy to integrate into a wide range of two-channel audio systems.

Combining Class A/B amplification, a Rotel-built toroidal transformer, Moving Magnet Phono stage and practical analog connectivity, the A10MKII delivers the essential features required for an uncomplicated stereo listening system.
